| Motor Characteristics | BO43**—42MP—BO4326NBH2B03-92-24.0 | BO43**—42MP—BO4326NBH2B01-92-48.0 | BO43**—42MP—BO4326NBH2B02-92-36.0 |
|---|---|---|---|
| Voltage | 24.0 V | 48.0 V | 36.0 V |
| Terminal resistance | 0.21 Ω | 1.0 Ω | 0.45 Ω |
| No-load speed | 9200 rpm | 9200 rpm | 9200 rpm |
| No-load current | 0.6 mA | 0.3 mA | 0.5 mA |
| Stall torque | 2817 mNm | 2361 mNm | 2952 mNm |
| Stall current | 114 mA | 48 mA | 80 mA |
| Nominal torque | 194 mNm | 192 mNm | 190 mNm |
| Nominal speed | 7000 rpm | 7000 rpm | 7000 rpm |
| Nominal current | 7.2 mA | 3.6 mA | 4.8 mA |
| Max. output power | 678 W | 569 W | 711 W |
| Max. efficiency | 86 % | 84.8 % | 84.8 % |
| Back-EMF constant | 2.60 mV/rpm | 5.18 mV/rpm | 3.89 mV/rpm |
| Torque constant | 24.8 mNm/A | 49.5 mNm/A | 37.1 mNm/A |
| Speed/torque gradient | 3.3 rpm/mNm | 3.9 rpm/mNm | 3.1 rpm/mNm |
| Rotor inertia | 153 g·cm² | 153 g·cm² | 153 g·cm² |
| Weight | 132 g | 132 g | 132 g |
| Gearbox characteristics | Produkt | ||
|---|---|---|---|
| Gearbox stages | 1 | ||
| Reduction ratio | 3.65~8.63 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 2 | ||
| Reduction ratio | 28~58 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
||
| Gearbox stages | 3 | ||
| Reduction ratio | 67~393 | ||
| Max. rated torque |
|
||
| Max. momentary torque |
|
||
| Length（L） |
|
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | BO43**—42MP—BO4326NBH2B03-92-24.0 |
|---|---|
| Voltage | 24.0 V |
| Terminal resistance | 0.21 Ω |
| No-load speed | 9200 rpm |
| No-load current | 0.6 mA |
| Stall torque | 2817 mNm |
| Stall current | 114 mA |
| Nominal torque | 194 mNm |
| Nominal speed | 7000 rpm |
| Nominal current | 7.2 mA |
| Max. output power | 678 W |
| Max. efficiency | 86 % |
| Back-EMF constant | 2.60 mV/rpm |
| Torque constant | 24.8 mNm/A |
| Speed/torque gradient | 3.3 rpm/mNm |
| Rotor inertia | 153 g·cm² |
| Weight | 132 g |
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | BO43**—42MP—BO4326NBH2B01-92-48.0 |
|---|---|
| Voltage | 48.0 V |
| Terminal resistance | 1.0 Ω |
| No-load speed | 9200 rpm |
| No-load current | 0.3 mA |
| Stall torque | 2361 mNm |
| Stall current | 48 mA |
| Nominal torque | 192 mNm |
| Nominal speed | 7000 rpm |
| Nominal current | 3.6 mA |
| Max. output power | 569 W |
| Max. efficiency | 84.8 % |
| Back-EMF constant | 5.18 mV/rpm |
| Torque constant | 49.5 mNm/A |
| Speed/torque gradient | 3.9 rpm/mNm |
| Rotor inertia | 153 g·cm² |
| Weight | 132 g |
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | BO43**—42MP—BO4326NBH2B02-92-36.0 |
|---|---|
| Voltage | 36.0 V |
| Terminal resistance | 0.45 Ω |
| No-load speed | 9200 rpm |
| No-load current | 0.5 mA |
| Stall torque | 2952 mNm |
| Stall current | 80 mA |
| Nominal torque | 190 mNm |
| Nominal speed | 7000 rpm |
| Nominal current | 4.8 mA |
| Max. output power | 711 W |
| Max. efficiency | 84.8 % |
| Back-EMF constant | 3.89 mV/rpm |
| Torque constant | 37.1 mNm/A |
| Speed/torque gradient | 3.1 rpm/mNm |
| Rotor inertia | 153 g·cm² |
| Weight | 132 g |
Applications
medical equipment
scientific instruments
industrial equipment
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
