![HRSM - Size 14 [35mm]](https://www.kocoautomotive.com/wp-content/uploads/2024/06/hybrid-rotary_35mm-300x300.png.webp)
| Characteristics | L1020N5M50-453-3.8 | L1020N5M66-336-7.4 | L1020N5M69-291-5.0 |
|---|---|---|---|
| Voltage | 3.8 V | 7.4 V | 5.0 V |
| Terminal resistance | 0.2 Ω | 1.8 Ω | 1.4 Ω |
| No-load speed | 45300 rpm | 33600 rpm | 29100 rpm |
| No-load current | 275 mA | 65 mA | 32 mA |
| Stall torque | 14.8 mNm | 8.4 mNm | 5.8 mNm |
| Stall current | 18095 mA | 4111 mA | 3597 mA |
| Load torque | 2.0 mNm | 2.0 mNm | 2.0 mNm |
| Load speed | 39170 rpm | 25580 rpm | 18990 rpm |
| Load current | 2690 mA | 1030 mA | 1270 mA |
| Max. output power | 17.5 W | 7.4 W | 4.4 W |
| Max. efficiency | 81 % | 77 % | 82 % |
| Back-EMF constant | 0.1 mV/rpm | 0.2 mV/rpm | 0.2 mV/rpm |
| Torque constant | 0.8 mNm/A | 2.1 mNm/A | 1.6 mNm/A |
| Speed/torque gradient | 3060 rpm/mNm | 4010 rpm/mNm | 5060 rpm/mNm |
| Rotor inertia | 0.15 g·cm² | 0.15 g·cm² | 0.12 g·cm² |
| Weight | 7.5 g | 7.5 g | 6.8 g |
| Operating temperature range | -20~+85 | -20~+85 | -20~+85 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L1020N5M50-453-3.8 |
|---|---|
| Voltage | 3.8 V |
| Terminal resistance | 0.2 Ω |
| No-load speed | 45300 rpm |
| No-load current | 275 mA |
| Stall torque | 14.8 mNm |
| Stall current | 18095 mA |
| Load torque | 2.0 mNm |
| Load speed | 39170 rpm |
| Load current | 2690 mA |
| Max. output power | 17.5 W |
| Max. efficiency | 81 % |
| Back-EMF constant | 0.1 mV/rpm |
| Torque constant | 0.8 mNm/A |
| Speed/torque gradient | 3060 rpm/mNm |
| Rotor inertia | 0.15 g·cm² |
| Weight | 7.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L1020N5M66-336-7.4 |
|---|---|
| Voltage | 7.4 V |
| Terminal resistance | 1.8 Ω |
| No-load speed | 33600 rpm |
| No-load current | 65 mA |
| Stall torque | 8.4 mNm |
| Stall current | 4111 mA |
| Load torque | 2.0 mNm |
| Load speed | 25580 rpm |
| Load current | 1030 mA |
| Max. output power | 7.4 W |
| Max. efficiency | 77 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 2.1 mNm/A |
| Speed/torque gradient | 4010 rpm/mNm |
| Rotor inertia | 0.15 g·cm² |
| Weight | 7.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L1020N5M69-291-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 1.4 Ω |
| No-load speed | 29100 rpm |
| No-load current | 32 mA |
| Stall torque | 5.8 mNm |
| Stall current | 3597 mA |
| Load torque | 2.0 mNm |
| Load speed | 18990 rpm |
| Load current | 1270 mA |
| Max. output power | 4.4 W |
| Max. efficiency | 82 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 1.6 mNm/A |
| Speed/torque gradient | 5060 rpm/mNm |
| Rotor inertia | 0.12 g·cm² |
| Weight | 6.8 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
