Description
Precious Metal Commutation
Precious Metal Commutation
Specification | L1020N5M50-453-3.8 |
---|---|
Voltage | 3.8 V |
Terminal resistance | 0.2 Ω |
No-load speed | 45300 rpm |
No-load current | 275 mA |
Stall torque | 14.8 mNm |
Stall current | 18095 mA |
Load torque | 2.0 mNm |
Load speed | 39170 rpm |
Load current | 2690 mA |
Max. output power | 17.5 W |
Max. efficiency | 81 % |
Back-EMF constant | 0.1 mV/rpm |
Torque constant | 0.8 mNm/A |
Speed/torque gradient | 3060 rpm/mNm |
Rotor inertia | 0.15 g·cm² |
Weight | 7.5 g |
Operating temperature range | -20~+85 ℃ |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
