Description
Graphite Brush
| Specification | C2032F41-0141 |
|---|---|
| Voltage | 6.0 V |
| No-load speed | 7400 rpm |
| No-load current | 89 mA |
| Stall torque | 12.1 mNm |
| Stall current | 1576 mA |
| Load torque | 1.80 mNm |
| Load speed | 6300 rpm |
| Load current | 310 mA |
| Max. output power | 2.35 W |
| Max. efficiency | 64.9 % |
| Torque constant | 8.14 mNm/A |
| Speed/torque gradient | 611 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 33 g |
| Operating temperature range | 0~+60 °C |
Applications
small electronic products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
