| Characteristics | L0710N5M61-780-8.0 | L0710N5M51-325-3.0 | L0710N5M08-618-5.0 |
|---|---|---|---|
| Voltage | 8.0 V | 3.0 V | 5.0 V |
| Terminal resistance | 7.2 Ω | 6.3 Ω | 3.4 Ω |
| No-load speed | 78050 rpm | 32500 rpm | 61800 rpm |
| No-load current | 95 mA | 50 mA | 80 mA |
| Stall torque | 0.9 mNm | 0.3 mNm | 1.0 mNm |
| Stall current | 1110 mA | 480 mA | 1470 mA |
| Load torque | 0.55 mNm | 0.12 mNm | 0.12 mNm |
| Load speed | 30880 rpm | 20890 rpm | 54500 rpm |
| Load current | 710 mA | 200 mA | 240 mA |
| Max. output power | 1.9 W | 0.29 W | 1.65 W |
| Max. efficiency | 50.2 % | 45.4 % | 58.9 % |
| Back-EMF constant | 0.09 mV/rpm | 0.08 mV/rpm | 0.08 mV/rpm |
| Torque constant | 0.90 mNm/A | 0.79 mNm/A | 0.73 mNm/A |
| Speed/torque gradient | 85769 rpm/mNm | 96726 rpm/mNm | 60827 rpm/mNm |
| Rotor inertia | 0.02 g·cm² | 0.02 g·cm² | 0.02 g·cm² |
| Weight | 1.6 g | 1.6 g | 1.6 g |
| Operating temperature range | -20~+100 | -20~+100 | -20~+100 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0710N5M61-780-8.0 |
|---|---|
| Voltage | 8.0 V |
| Terminal resistance | 7.2 Ω |
| No-load speed | 78050 rpm |
| No-load current | 95 mA |
| Stall torque | 0.9 mNm |
| Stall current | 1110 mA |
| Load torque | 0.55 mNm |
| Load speed | 30880 rpm |
| Load current | 710 mA |
| Max. output power | 1.9 W |
| Max. efficiency | 50.2 % |
| Back-EMF constant | 0.09 mV/rpm |
| Torque constant | 0.90 mNm/A |
| Speed/torque gradient | 85769 rpm/mNm |
| Rotor inertia | 0.02 g·cm² |
| Weight | 1.6 g |
| Operating temperature range | -20~+100 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0710N5M51-325-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 6.3 Ω |
| No-load speed | 32500 rpm |
| No-load current | 50 mA |
| Stall torque | 0.3 mNm |
| Stall current | 480 mA |
| Load torque | 0.12 mNm |
| Load speed | 20890 rpm |
| Load current | 200 mA |
| Max. output power | 0.29 W |
| Max. efficiency | 45.4 % |
| Back-EMF constant | 0.08 mV/rpm |
| Torque constant | 0.79 mNm/A |
| Speed/torque gradient | 96726 rpm/mNm |
| Rotor inertia | 0.02 g·cm² |
| Weight | 1.6 g |
| Operating temperature range | -20~+100 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0710N5M08-618-5.0 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 3.4 Ω |
| No-load speed | 61800 rpm |
| No-load current | 80 mA |
| Stall torque | 1.0 mNm |
| Stall current | 1470 mA |
| Load torque | 0.12 mNm |
| Load speed | 54500 rpm |
| Load current | 240 mA |
| Max. output power | 1.65 W |
| Max. efficiency | 58.9 % |
| Back-EMF constant | 0.08 mV/rpm |
| Torque constant | 0.73 mNm/A |
| Speed/torque gradient | 60827 rpm/mNm |
| Rotor inertia | 0.02 g·cm² |
| Weight | 1.6 g |
| Operating temperature range | -20~+100 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
