| Characteristics | L0412N3M71-680-3.4 | L0412N3M65-650-3.4 | L0412N3M60-600-3.4 | L0412N3M75-430-3.4 |
|---|---|---|---|---|
| Voltage | 3.4 V | 3.4 V | 3.4 V | 3.4 V |
| Terminal resistance | 7.00 Ω | 8.30 Ω | 8.70 Ω | 20.00 Ω |
| No-load speed | 68000 rpm | 65000 rpm | 60000 rpm | 43000 rpm |
| No-load current | 60 mA | 55 mA | 50 mA | 30 mA |
| Stall torque | 0.18 mNm | 0.15 mNm | 0.16 mNm | 0.09 mNm |
| Stall current | 486 mA | 410 mA | 391 mA | 170 mA |
| Load torque | 0.03 mNm | 0.03 mNm | 0.03 mNm | 0.03 mNm |
| Load speed | 56540 rpm | 52250 rpm | 48820 rpm | 28170 rpm |
| Load current | 130 mA | 120 mA | 110 mA | 80 mA |
| Max. output power | 0.32 W | 0.26 W | 0.25 W | 0.10 W |
| Max. efficiency | 42.1 % | 40.1 % | 41.3 % | 33.6 % |
| Back-EMF constant | 0.04 mV/rpm | 0.05 mV/rpm | 0.05 mV/rpm | 0.07 mV/rpm |
| Torque constant | 0.42 mNm/A | 0.43 mNm/A | 0.47 mNm/A | 0.62 mNm/A |
| Speed/torque gradient | 382022 rpm/mNm | 424837 rpm/mNm | 372671 rpm/mNm | 494253 rpm/mNm |
| Rotor inertia | 0.005 g·cm² | 0.005 g·cm² | 0.005 g·cm² | 0.005 g·cm² |
| Weight | 0.8 g | 0.8 g | 0.7 g | 0.7 g |
| Operating temperature range | -20~+65 | -20~+65 | -20~+65 | -20~+65 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0412N3M71-680-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 7.00 Ω |
| No-load speed | 68000 rpm |
| No-load current | 60 mA |
| Stall torque | 0.18 mNm |
| Stall current | 486 mA |
| Load torque | 0.03 mNm |
| Load speed | 56540 rpm |
| Load current | 130 mA |
| Max. output power | 0.32 W |
| Max. efficiency | 42.1 % |
| Back-EMF constant | 0.04 mV/rpm |
| Torque constant | 0.42 mNm/A |
| Speed/torque gradient | 382022 rpm/mNm |
| Rotor inertia | 0.005 g·cm² |
| Weight | 0.8 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0412N3M65-650-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 8.30 Ω |
| No-load speed | 65000 rpm |
| No-load current | 55 mA |
| Stall torque | 0.15 mNm |
| Stall current | 410 mA |
| Load torque | 0.03 mNm |
| Load speed | 52250 rpm |
| Load current | 120 mA |
| Max. output power | 0.26 W |
| Max. efficiency | 40.1 % |
| Back-EMF constant | 0.05 mV/rpm |
| Torque constant | 0.43 mNm/A |
| Speed/torque gradient | 424837 rpm/mNm |
| Rotor inertia | 0.005 g·cm² |
| Weight | 0.8 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0412N3M60-600-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 8.70 Ω |
| No-load speed | 60000 rpm |
| No-load current | 50 mA |
| Stall torque | 0.16 mNm |
| Stall current | 391 mA |
| Load torque | 0.03 mNm |
| Load speed | 48820 rpm |
| Load current | 110 mA |
| Max. output power | 0.25 W |
| Max. efficiency | 41.3 % |
| Back-EMF constant | 0.05 mV/rpm |
| Torque constant | 0.47 mNm/A |
| Speed/torque gradient | 372671 rpm/mNm |
| Rotor inertia | 0.005 g·cm² |
| Weight | 0.7 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
| Specification | L0412N3M75-430-3.4 |
|---|---|
| Voltage | 3.4 V |
| Terminal resistance | 20.00 Ω |
| No-load speed | 43000 rpm |
| No-load current | 30 mA |
| Stall torque | 0.09 mNm |
| Stall current | 170 mA |
| Load torque | 0.03 mNm |
| Load speed | 28170 rpm |
| Load current | 80 mA |
| Max. output power | 0.10 W |
| Max. efficiency | 33.6 % |
| Back-EMF constant | 0.07 mV/rpm |
| Torque constant | 0.62 mNm/A |
| Speed/torque gradient | 494253 rpm/mNm |
| Rotor inertia | 0.005 g·cm² |
| Weight | 0.7 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
