| Characteristics | C1220F35-0083 | C1220F35-0103 | C1220F35-0158 |
|---|---|---|---|
| Voltage | 6.0 V | 5.0 V | 4.5 V |
| Terminal resistance | 7.4 Ω | 2.5 Ω | 10 Ω |
| No-load speed | 13800 rpm | 18500 rpm | 9500 rpm |
| No-load current | 50 mA | 70 mA | 45 mA |
| Stall torque | 2.60 mNm | 3.60 mNm | 1.70 mNm |
| Stall current | 846 mA | 2043 mA | 693 mA |
| Load torque | 0.294 mNm | 0.294 mNm | 0.196 mNm |
| Load speed | 12240 rpm | 17000 rpm | 8400 rpm |
| Load current | 140 mA | 230 mA | 120 mA |
| Max. output power | 0.94 W | 1.75 W | 0.42 W |
| Max. efficiency | 48.0 % | 48.7 % | 34.5 % |
| Back-EMF constant | 0.41 mV/rpm | 0.26 mV/rpm | 0.43 mV/rpm |
| Torque constant | 3.27 mNm/A | 1.82 mNm/A | 2.62 mNm/A |
| Speed/torque gradient | 5306 rpm/mNm | 5139 rpm/mNm | 5588 rpm/mNm |
| Varistor | Yes | Yes | Yes |
| Weight | 7.9 g | 7.8 g | 7.8 g |
| Operating temperature range | -20~+80 | -20~+80 | -20~+80 |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | C1220F35-0083 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 7.4 Ω |
| No-load speed | 13800 rpm |
| No-load current | 50 mA |
| Stall torque | 2.60 mNm |
| Stall current | 846 mA |
| Load torque | 0.294 mNm |
| Load speed | 12240 rpm |
| Load current | 140 mA |
| Max. output power | 0.94 W |
| Max. efficiency | 48.0 % |
| Back-EMF constant | 0.41 mV/rpm |
| Torque constant | 3.27 mNm/A |
| Speed/torque gradient | 5306 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 7.9 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | C1220F35-0103 |
|---|---|
| Voltage | 5.0 V |
| Terminal resistance | 2.5 Ω |
| No-load speed | 18500 rpm |
| No-load current | 70 mA |
| Stall torque | 3.60 mNm |
| Stall current | 2043 mA |
| Load torque | 0.294 mNm |
| Load speed | 17000 rpm |
| Load current | 230 mA |
| Max. output power | 1.75 W |
| Max. efficiency | 48.7 % |
| Back-EMF constant | 0.26 mV/rpm |
| Torque constant | 1.82 mNm/A |
| Speed/torque gradient | 5139 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 7.8 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | C1220F35-0158 |
|---|---|
| Voltage | 4.5 V |
| Terminal resistance | 10 Ω |
| No-load speed | 9500 rpm |
| No-load current | 45 mA |
| Stall torque | 1.70 mNm |
| Stall current | 693 mA |
| Load torque | 0.196 mNm |
| Load speed | 8400 rpm |
| Load current | 120 mA |
| Max. output power | 0.42 W |
| Max. efficiency | 34.5 % |
| Back-EMF constant | 0.43 mV/rpm |
| Torque constant | 2.62 mNm/A |
| Speed/torque gradient | 5588 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 7.8 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
