| Characteristics | C1015F33-0107 | C1015F33-0051 | C1015F33-0169 |
|---|---|---|---|
| Voltage | 6.0 V | 3.0 V | 3.0 V |
| Terminal resistance | 10 Ω | 35 Ω | 4.5 Ω |
| No-load speed | 20500 rpm | 5500 rpm | 14700 rpm |
| No-load current | 35 mA | 15 mA | 50 mA |
| Stall torque | 1.30 mNm | 0.40 mNm | 1.0 mNm |
| Stall current | 582 mA | 91 mA | 680 mA |
| Load torque | 0.098 mNm | 0.098 mNm | 0.098 mNm |
| Load speed | 19000 rpm | 4200 rpm | 13300 rpm |
| Load current | 75 mA | 33 mA | 110 mA |
| Max. output power | 0.70 W | 0.06 W | 0.38 W |
| Max. efficiency | 51.6 % | 42.7 % | 45.8 % |
| Back-EMF constant | 0.28 mV/rpm | 0.45 mV/rpm | 0.19 mV/rpm |
| Torque constant | 2.38 mNm/A | 5.25 mNm/A | 1.56 mNm/A |
| Speed/torque gradient | 15769 rpm/mNm | 13750 rpm/mNm | 15000 rpm/mNm |
| Varistor | Yes | Yes | Yes |
| Weight | 4.1 g | 3.9 g | 4.0 g |
| Operating temperature range | -20~+80 | -20~+80 | -20~+80 |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | C1015F33-0107 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 10 Ω |
| No-load speed | 20500 rpm |
| No-load current | 35 mA |
| Stall torque | 1.30 mNm |
| Stall current | 582 mA |
| Load torque | 0.098 mNm |
| Load speed | 19000 rpm |
| Load current | 75 mA |
| Max. output power | 0.70 W |
| Max. efficiency | 51.6 % |
| Back-EMF constant | 0.28 mV/rpm |
| Torque constant | 2.38 mNm/A |
| Speed/torque gradient | 15769 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 4.1 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | C1015F33-0051 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 35 Ω |
| No-load speed | 5500 rpm |
| No-load current | 15 mA |
| Stall torque | 0.40 mNm |
| Stall current | 91 mA |
| Load torque | 0.098 mNm |
| Load speed | 4200 rpm |
| Load current | 33 mA |
| Max. output power | 0.06 W |
| Max. efficiency | 42.7 % |
| Back-EMF constant | 0.45 mV/rpm |
| Torque constant | 5.25 mNm/A |
| Speed/torque gradient | 13750 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 3.9 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | C1015F33-0169 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 4.5 Ω |
| No-load speed | 14700 rpm |
| No-load current | 50 mA |
| Stall torque | 1.0 mNm |
| Stall current | 680 mA |
| Load torque | 0.098 mNm |
| Load speed | 13300 rpm |
| Load current | 110 mA |
| Max. output power | 0.38 W |
| Max. efficiency | 45.8 % |
| Back-EMF constant | 0.19 mV/rpm |
| Torque constant | 1.56 mNm/A |
| Speed/torque gradient | 15000 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 4.0 g |
| Operating temperature range | -20~+80 °C |
Applications
security equipment
small electronic products
remote control model aircraft
personal care products
portable electric tools
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
