| Characteristics | L1213N5M01-185-7.4 | L1213N5M02-300-6.0 | L1213N5M05-400-7.4 |
|---|---|---|---|
| Voltage | 7.4 V | 6.0 V | 7.4 V |
| Terminal resistance | 14.5 Ω | 4.0 Ω | 3.2 Ω |
| No-load speed | 18500 rpm | 30000 rpm | 40500 rpm |
| No-load current | 10 mA | 25 mA | 120 mA |
| Stall torque | 1.9 mNm | 2.8 mNm | 3.7 mNm |
| Stall current | 510 mA | 1500 mA | 2350 mA |
| Load torque | 0.5 mNm | 0.5 mNm | 0.5 mNm |
| Load speed | 13560 rpm | 24590 rpm | 35020 rpm |
| Load current | 140 mA | 290 mA | 420 mA |
| Max. output power | 0.9 W | 2.2 W | 3.9 W |
| Max. efficiency | 74 % | 76 % | 60 % |
| Back-EMF constant | 0.4 mV/rpm | 0.2 mV/rpm | 0.2 mV/rpm |
| Torque constant | 3.7 mNm/A | 1.9 mNm/A | 1.7 mNm/A |
| Speed/torque gradient | 9880 rpm/mNm | 10830 rpm/mNm | 10970 rpm/mNm |
| Rotor inertia | 0.1 g·cm² | 0.1 g·cm² | 0.1 g·cm² |
| Weight | 6.5 g | 6.5 g | 5.6 g |
| Operating temperature range | -20~+85 | -20~+85 | -20~+85 |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | L1213N5M01-185-7.4 |
|---|---|
| Voltage | 7.4 V |
| Terminal resistance | 14.5 Ω |
| No-load speed | 18500 rpm |
| No-load current | 10 mA |
| Stall torque | 1.9 mNm |
| Stall current | 510 mA |
| Load torque | 0.5 mNm |
| Load speed | 13560 rpm |
| Load current | 140 mA |
| Max. output power | 0.9 W |
| Max. efficiency | 74 % |
| Back-EMF constant | 0.4 mV/rpm |
| Torque constant | 3.7 mNm/A |
| Speed/torque gradient | 9880 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 6.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | L1213N5M02-300-6.0 |
|---|---|
| Voltage | 6.0 V |
| Terminal resistance | 4.0 Ω |
| No-load speed | 30000 rpm |
| No-load current | 25 mA |
| Stall torque | 2.8 mNm |
| Stall current | 1500 mA |
| Load torque | 0.5 mNm |
| Load speed | 24590 rpm |
| Load current | 290 mA |
| Max. output power | 2.2 W |
| Max. efficiency | 76 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 1.9 mNm/A |
| Speed/torque gradient | 10830 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 6.5 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Produkt
| Specification | L1213N5M05-400-7.4 |
|---|---|
| Voltage | 7.4 V |
| Terminal resistance | 3.2 Ω |
| No-load speed | 40500 rpm |
| No-load current | 120 mA |
| Stall torque | 3.7 mNm |
| Stall current | 2350 mA |
| Load torque | 0.5 mNm |
| Load speed | 35020 rpm |
| Load current | 420 mA |
| Max. output power | 3.9 W |
| Max. efficiency | 60 % |
| Back-EMF constant | 0.2 mV/rpm |
| Torque constant | 1.7 mNm/A |
| Speed/torque gradient | 10970 rpm/mNm |
| Rotor inertia | 0.1 g·cm² |
| Weight | 5.6 g |
| Operating temperature range | -20~+85 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
