Description
Precious Metal Commutation
| Specification | C1012F43-0108 |
|---|---|
| Voltage | 2.0 V |
| Terminal resistance | 16.5 Ω |
| No-load speed | 7000 rpm |
| No-load current | 20 mA |
| Stall torque | 0.30 mNm |
| Stall current | 120 mA |
| Load torque | 0.09 mNm |
| Load speed | 4900 rpm |
| Load current | 50 mA |
| Max. output power | 0.06 W |
| Max. efficiency | 46.3 % |
| Back-EMF constant | 0.24 mV/rpm |
| Torque constant | 3.00 mNm/A |
| Speed/torque gradient | 23333 rpm/mNm |
| Varistor | Yes Yes/No |
| Weight | 3 g |
| Operating temperature range | -20~+80 °C |
