Description
Precious Metal Commutation
| Parameter | L0614N5M44-125-3.0 |
|---|---|
| Voltage | 3.0 V |
| Terminal resistance | 23.1 Ω |
| No-load speed | 12540 rpm |
| No-load current | 7.4 mA |
| Stall torque | 0.26 mNm |
| Stall current | 130 mA |
| Load torque | 0.05 mNm |
| Load speed | 10170 rpm |
| Load current | 30 mA |
| Max. output power | 0.09 W |
| Max. efficiency | 58.1 % |
| Back-EMF constant | 0.23 mV/rpm |
| Torque constant | 2.15 mNm/A |
| Speed/torque gradient | 47500 rpm/mNm |
| Rotor inertia | 0.016 g·cm² |
| Weight | 1.7 g |
| Operating temperature range | -20~+65 ℃ |
Applications
mini UAV
remote control hobby products
small household appliances
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
