Description
Precious Metal Commutation
Precious Metal Commutation
Specification | 1020RFN31-17d-3.0 |
---|---|
Voltage | 3.0 V |
Terminal resistance | 30/58 Ω |
Speed | 13500 rpm |
Current | 60 mA |
Starting voltage | 2.3 V |
Stall current | 95 mA |
Operating temperature range | -20~+70 ℃ |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
