Description
Precious Metal Commutation
Precious Metal Commutation
Specification | 0615N5M02-185-3.0 |
---|---|
Voltage | 3.0 V |
Terminal resistance | 18.5 Ω |
No-load speed | 18500 rpm |
No-load current | 18 mA |
Stall torque | 0.20 mNm |
Stall current | 160 mA |
Nominal torque | 0.05 mNm |
Nominal speed | 13770 rpm |
Nominal current | 50 mA |
Max. output power | 0.09 W |
Max. efficiency | 44 % |
Back-EMF constant | 0.1 mV/rpm |
Torque constant | 1.4 mNm/A |
Speed/torque gradient | 94600 rpm/mNm |
Rotor inertia | 0.015 g·cm² |
Weight | 2.5 g |
Thermal resistance housing-ambient | 75.83 K/W |
Thermal resistance winding-housing | 42.08 K/W |
Thermal time constant motor | 78 s |
Thermal time constant winding | 15 s |
Operating temperature range | -20~+85 °C |
Thermal class of winding | 130 °C |
Axial play | ≤0.3 mm |
Radial play | 0.012 mm |
Axial load dynamic | 0.15 N |
Axial load static | 10 N |
Radial load at 3 mm from mounting face | 0.7 N |
No. of pole pairs | 1 |
Bearings | 2 sleeve bearings |
Commutator | metal 5 segments |
Protection class | 40 IP |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
