Beschreibung
16mm 12V coreless spur gearbox motor
Loggen Sie sich ein, um Preise für dieses Produkt zu sehen
inkl. 19 % MwSt.
16mm 12V coreless spur gearbox motor
16mm 12V coreless spur gearbox motor
Specification | 1638—16MS—1627N5M21-113-12.0 |
---|---|
Voltage | 12.0 V |
Terminal resistance | 11.8 Ω |
No-load speed | 11300 rpm |
No-load current | 13 mA |
Stall torque | 10.1 mNm |
Stall current | 1020 mA |
Nominal torque | 3.0 mNm |
Nominal speed | 7940 rpm |
Nominal current | 310 mA |
Max. output power | 3.0 W |
Max. efficiency | 79 % |
Back-EMF constant | 1.0 mV/rpm |
Torque constant | 10.0 mNm/A |
Speed/torque gradient | 1120 rpm/mNm |
Rotor inertia | 0.6 g·cm² |
Weight | 25 g |
Gearbox Characteristics | 1638—16MS—1627N5M21-113-12.0 | ||
---|---|---|---|
Gearbox stages | 2 | ||
Reduction ratio | 10 | ||
Max. rated torque |
|
||
Max. momentary torque |
|
||
Length(L) |
|
||
Gearbox stages | 3 | ||
Reduction ratio | 21.34 | ||
Max. rated torque |
|
||
Max. momentary torque |
|
||
Length(L) |
|
||
Gearbox stages | 4 | ||
Reduction ratio | 59.75 | ||
Max. rated torque |
|
||
Max. momentary torque |
|
||
Length(L) |
|
||
Gearbox stages | 4 | ||
Reduction ratio | 105.146 | ||
Max. rated torque |
|
||
Max. momentary torque |
|
||
Length(L) |
|
||
Gearbox stages | 5 | ||
Reduction ratio | 203.257.294.360 | ||
Max. rated torque |
|
||
Max. momentary torque |
|
||
Length(L) |
|
Technische Angaben dienen als Orientierungswerte, da die einzelnen Antriebe und Motoren anwendungsbezogen konfiguriert werden. Technische und optische Änderungen vorbehalten.
