Characteristics | 1735N5C2B01-128-12.0 | 1735N5C2B02-90-24.0 |
---|---|---|
Voltage | 12.0 V | 24.0 V |
Rotor resistance | 5.1 Ω | 34.5 Ω |
No-load speed | 12800 rpm | 9000 rpm |
No-load current | 20 mA | 10 mA |
Stall torque | 20.7 mNm | 17.3 mNm |
Stall current | 2350 mA | 700 mA |
Nominal torque | 5.0 mNm | 5.0 mNm |
Nominal speed | 9710 rpm | 6400 rpm |
Nominal current | 580 mA | 210 mA |
Max. output power | 6.9 W | 4.1 W |
Max. efficiency | 82 % | 78 % |
Back-EMF constant | 0.9 mV/rpm | 2.6 mV/rpm |
Torque constant | 8.9 mNm/A | 25.1 mNm/A |
Speed/torque gradient | 620 rpm/mNm | 520 rpm/mNm |
Rotor inertia | 0.95 g·cm² | 0.95 g·cm² |
Weight | 34 g | 34 g |
Thermal resistance housing-ambient | 25.7 K/W | 25.7 K/W |
Thermal resistance winding-housing | 30.4 K/W | 30.4 K/W |
Thermal time constant motor | 245 rpm | 245 rpm |
Thermal time constant winding | 232 s | 232 s |
Operating temperature range | -20~+85 | -20~+85 |
Thermal class of winding | 130 °C | 130 °C |
Axial play | 0.01~0.15 | 0.01~0.15 |
Radial play | 0.025 mm | 0.025 mm |
Axial load dynamic | 2.2 N | 2.2 N |
Axial load static | 30 N | 30 N |
Radial load at 3 mm from mounting face | 8 N | 8 N |
No. of pole pairs | 1 | 1 |
Bearings | 2 ball bearings | 2 ball bearings |
Commutator | metal 5 segments | metal 5 segments |
Protection class | 30 IP | 30 IP |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | 1735N5C2B01-128-12.0 |
---|---|
Voltage | 12.0 V |
Rotor resistance | 5.1 Ω |
No-load speed | 12800 rpm |
No-load current | 20 mA |
Stall torque | 20.7 mNm |
Stall current | 2350 mA |
Nominal torque | 5.0 mNm |
Nominal speed | 9710 rpm |
Nominal current | 580 mA |
Max. output power | 6.9 W |
Max. efficiency | 82 % |
Back-EMF constant | 0.9 mV/rpm |
Torque constant | 8.9 mNm/A |
Speed/torque gradient | 620 rpm/mNm |
Rotor inertia | 0.95 g·cm² |
Weight | 34 g |
Thermal resistance housing-ambient | 25.7 K/W |
Thermal resistance winding-housing | 30.4 K/W |
Thermal time constant motor | 245 rpm |
Thermal time constant winding | 232 s |
Operating temperature range | -20~+85 °C |
Thermal class of winding | 130 °C |
Axial play | 0.01~0.15 mm |
Radial play | 0.025 mm |
Axial load dynamic | 2.2 N |
Axial load static | 30 N |
Radial load at 3 mm from mounting face | 8 N |
No. of pole pairs | 1 |
Bearings | 2 ball bearings |
Commutator | metal 5 segments |
Protection class | 30 IP |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
Specification | 1735N5C2B02-90-24.0 |
---|---|
Voltage | 24.0 V |
Rotor resistance | 34.5 Ω |
No-load speed | 9000 rpm |
No-load current | 10 mA |
Stall torque | 17.3 mNm |
Stall current | 700 mA |
Nominal torque | 5.0 mNm |
Nominal speed | 6400 rpm |
Nominal current | 210 mA |
Max. output power | 4.1 W |
Max. efficiency | 78 % |
Back-EMF constant | 2.6 mV/rpm |
Torque constant | 25.1 mNm/A |
Speed/torque gradient | 520 rpm/mNm |
Rotor inertia | 0.95 g·cm² |
Weight | 34 g |
Thermal resistance housing-ambient | 25.7 K/W |
Thermal resistance winding-housing | 30.4 K/W |
Thermal time constant motor | 245 rpm |
Thermal time constant winding | 232 s |
Operating temperature range | -20~+85 °C |
Thermal class of winding | 130 °C |
Axial play | 0.01~0.15 mm |
Radial play | 0.025 mm |
Axial load dynamic | 2.2 N |
Axial load static | 30 N |
Radial load at 3 mm from mounting face | 8 N |
No. of pole pairs | 1 |
Bearings | 2 ball bearings |
Commutator | metal 5 segments |
Protection class | 30 IP |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
