Description
Precious Metal Commutation
Precious Metal Commutation
Specification | C1627F34AH-0064 |
---|---|
Voltage | 6.0 V |
Terminal resistance | 2.4 Ω |
No-load speed | 20200 rpm |
No-load current | 100 mA |
Stall torque | 5.40 mNm |
Stall current | 2304 mA |
Load torque | 0.39 mNm |
Load speed | 19100 rpm |
Load current | 220 mA |
Max. output power | 2.86 W |
Max. efficiency | 56.7 % |
Back-EMF constant | 0.29 mV/rpm |
Torque constant | 2.45 mNm/A |
Speed/torque gradient | 3741 rpm/mNm |
Varistor | Yes Yes/No |
Weight | 16.7 g |
Operating temperature range | -20~+80 °C |
Technical specifications are for guidance only, as the individual drives and motors are configured for specific applications. Subject to technical and visual changes.
